SMT PCB Assembly Fabricaion Services Lead Free SolderingFor
Industry Medical Consumer Electronics Filed
One stop services:
- PCB layout
- Electronic design
- Engineering
- PCB fabrication
- PCB Assembly
- Box Build
- IC Programming
- Testing
- Parts sourcing
- Supply management
- After sales servies etc
PCB capability and services:
1. Single-sided, double-sided & multi-layer PCB (up to 30 layers)
2. Flexible PCB (up to 10 layers)
3. Rigid-flex PCB (up to 8 layers)
4. CEM-1, CEM-3 FR-4, FR-4 High TG, Polyimide, Aluminum-based
material.
5. HAL, HAL lead free, Immersion Gold/ Silver/Tin, Hard Gold, OSP
surface treatment.
6. Printed Circuit Boards are 94V0 compliant, and adhere to IPC610
Class 2 international PCB standard.
7. Quantities range from prototype to volume production.
8. 100% E-Test
FAQ
Q: What files do you use in PCB fabrication?
A: Gerber or Eagle, BOM listing, PNP and Components Position
Q:Is it possible you could offer sample?
A: Yes, we can custom you sample to test before mass production
Q: When will I get the quotation after sent Gerber, BOM and test
procedure?
A: Within 6 hours for PCB quotation and around 24-48 hours for PCBA
quotation.
Q: How can I know the process of my PCB production?
A: 5-7days for PCB production and components purchasing, and 14
days for PCB assembly and Testing
Q: How can I make sure the quality of my PCB?
A: We ensure that each piece of PCB products work well before
shipping. We'll test all of them according to your test procedure.
| PCBA | PCB+components sourcing+assembly+package |
| Assembly details | SMT and Thru-hole, ISO SMT and DIP lines |
| Lead Time | Prototype: 15 work days. Mass order: 20~25 work days |
| Testing on products | Flying Probe Test, X-ray Inspection, AOI Test, Functional test |
| Quantity | Min quantity: 1pcs. Prototype, small order, mass order, all OK |
| Files needed | PCB: Gerber files(CAM, PCB, PCBDOC) |
| Components: Bill of Materials(BOM list) |
| Assembly: Pick-N-Place file |
| PCB Panel Size | Min size: 0.25*0.25 inches(6*6mm) |
| Max size: 20*20 inches(500*500mm) |
| PCB Solder Type | Water Soluble Solder Paste, RoHS lead free |
| Components details | Passive Down to 0201 size |
| BGA and VFBGA |
| Leadless Chip Carriers/CSP |
| Double-sided SMT Assembly |
| Fine Pitch to 0.8mils |
| BGA Repair and Reball |
| Part Removal and Replacement |
| Component package | Cut Tape,Tube,Reels,Loose Parts |
PCB assembly
process | Drilling-----Exposure-----Plating-----Etaching &
Stripping-----Punching-----Electrical Testing-----SMT-----Wave
Soldering-----Assembling-----ICT-----Function
Testing-----Temperature & Humidity Testing |
PCB Assembly services:
SMT Assembly
Automatic Pick & Place
Component Placement as Small as 0201
Fine Pitch QEP - BGA
Automatic Optical Inspection
Through-hole Assembly
Wave Soldering
Hand Assembly and Soldering
Material Sourcing
IC pre-programming / Burning on-line
Function testing as requested
Aging test for LED and Power boards
Complete unit assembly (which including plastics, metal box, Coil,
cable assembly etc)
Packing design
Certificate:
IPC Standard
ISO9001
ISO/TS16949
UL
Testing and value added services:
AOI (Automatic optical inspection)
ICT(In-circuit test)
Reliability test
X-Ray Test
Analogue and digital function test
Firmware programming
Shipping Method and Payment terms:
1. By DHL, UPS, FedEx, TNT, or using clients account.
2. We suggest you using our DHL, UPS, FedEx, TNT forwarder for cost
saving.
3. By sea for mass quantity according to customer's requirement.
4. By customer's Forwarder
6. T/T, West Union, etc.
